Hubbell Wiring Device-Kellems HBL14W47A HWD 1-Phase Standard Watertight Cord Mount Plug 125 VAC

Product Description

The Hubbell Wiring Device-Kellems HBL14W47A is a straight blade plug designed for heavy-duty applications. This device is suitable for watertight installations and operates at a voltage of 125 VAC with a current rating of 15 A. The plug features two poles and three wires and is compatible with cords ranging from three eighths to five eighths inches in diameter. It is ideal for commercial and industrial settings that require reliable and safe electrical connections.

• Standard watertight cord mount plug
• Rated for use in environments with temperatures from -40 to 75 degrees Celsius
• Built according to UL 498 and NEMA standards, ensuring compliance and safety

Product Highlights

This plug is designed for demanding applications, providing robust performance in harsh conditions while ensuring user safety and functionality.

Product Information

Standard Information

• Brand: Hubbell Wiring Device-Kellems
• MPN: HBL14W47A

Technical Specifications

• Voltage Rating: 125 VAC
• Amperage Rating: 15 A
• Horsepower: 1/2 hp
• Number of Wires: 3
• Number of Poles: 2
• Temperature Rating: -40 to 75 degrees Celsius
• Cord Diameter: 3/8 to 5/8 inches
• NEMA Rating: 5-15P
• Material: Elastomer/Composite
• Enclosure Rating: NEMA 4, 4X, 6, 6P, 12
