Hubbell T2530144S T2-53014-4S-ELEC 5KVA Dry-Type Transformer 240X480 Primary - 120/240 Secondary - Four Windings

Product Description

The Hubbell T2530144S is a 5 kVA dry-type transformer designed for various applications. It features a 240/480 VAC primary and a 120/240 VAC secondary with four windings. This transformer is suitable for both indoor and outdoor use, allowing for versatile installation options.

• 5 kVA power rating for robust performance
• Wall-mount design for easy installation
• Steel housing with NEMA 3R rating for protection

Product Highlights

This transformer is engineered for quiet operation while maintaining efficiency. It uses an electrostatic shield for added protection from electrical disturbances.

Product Information

Standard Information

• Manufacturer: Hubbell
• Model Number: T2530144S

Technical Specifications

• Application: Indoor/Outdoor Applications
• Connection Type: Copper Lead Wire Screw Terminal
• Dimensions: 7.13 in L x 10.31 in W x 14.38 in H
• Enclosure: NEMA 3R
• Frequency Rating: 60 Hz
• Housing Material: Steel
• Insulation: 180 deg C Class H
• Mounting Type: Wall
• Number of Taps: 4
• Phase: 1 ph
• Power Rating: 5 kVA
• Secondary Voltage: 120/240 VAC
• Temperature Rating: 115 deg C
• Standards/Approvals: ANSI Specified|UL 506|E79947V1/50B8|X3221|CSA C802.2|IEEE Standard|OSHA Approved|PROP65: Cancer and Reproductive Harm
• Prop65 Message: WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov
