Hubbell T253009S T2-53009-S-ELEC 0.75KVA DRY-TYPE TRANSFORMER 240X480 PRIMARY - 120/240 SECONDARY

Product Description

Hubbell T253009S is a distribution transformer designed for multi-use applications. It features a primary voltage of 240 or 480 VAC and a secondary voltage of 120 or 240 VAC. This unit has a power rating of 0.75 kVA, suitable for various industrial and commercial settings.

• Designed for both indoor and outdoor use.
• Air cooled and dry type transformer.
• UL type 3R enclosure ensures protection.

Product Highlights

Features encapsulated core and coil for moisture resistance. This transformer operates quietly and efficiently under typical load conditions.

Product Information

Standard Information

• Manufacturer: Hubbell
• Power Rating: 0.75 kVA

Technical Specifications

• Connection Type: Wire Lead
• Dimensions: 4.5 in L x 4.75 in W x 9.68 in H
• Enclosure: NEMA 3R
• Frequency Rating: 50/60 Hz
• Housing Material: Steel
• Insulation: Class H/180 deg C
• Maximum Amperage Rating: 5.2 A (240 VAC), 2.7 A (480 VAC), 10 A (120 VAC)
• Mounting Type: Wall
• Phase: 1 ph
• Prop65 Message: WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov
• Secondary Voltage: 120/240 VAC
• Temperature Rating: 115 deg C
