Hubbell T253008S T2-53008-S-ELEC 0.5KVA Dry-Type Transformer 240X480 Primary - 120/240 Secondary - Four Windings

Product Description

Hubbell T253008S is a dry-type distribution transformer designed for industrial use. The transformer operates at a primary voltage of 240 to 480 VAC and provides a secondary voltage of 120 to 240 VAC. It has a power rating of 0.5 kVA and can operate at frequencies of 50 or 60 Hz.

• Air cooled for efficient heat dissipation
• Wall mountable for flexible installation
• NEMA 3R enclosure for robust protection

Product Highlights

The Hubbell T253008S is ideal for harsh industrial environments. It features a durable design that withstands corrosive conditions.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: T253008S

Technical Specifications

• Application: Harsh Industrial Locations, Corrosive Chemical Exposure and Waste Water Treatment Facilities
• Connection Type: Wire Lead
• Dimensions: 4.2 inches L x 4.37 inches W x 9.06 inches H
• Enclosure: NEMA 3R
• Frequency Rating: 50/60 Hz
• Insulation: 155 degrees C
• Maximum Amperage Rating: 1.7/3.5/7 A
• Mounting Type: Wall
• Phase: 1 ph
• Power Rating: 0.5 kVA
• Secondary Voltage: 120/240 VAC
• Temperature Rating: 115 degrees C
• Standards/Approvals: UL 506, CSA Certified, OSHA Approved
