Hubbell T253007S T2-53007-S-ELEC 0.25KVA Dry-Type Transformer 240X480 Primary - 120/240 Secondary - Four Windings - 1PH, 60 Hz

Product Description

Hubbell T253007S is a dry-type transformer designed for various industrial and commercial uses. This transformer features a primary voltage of two hundred forty to four hundred eighty volts, and a secondary voltage of one hundred twenty to two hundred forty volts. It provides a power rating of zero point twenty-five kVA with a frequency range of fifty to sixty hertz.

• Shielded design for cleaner power
• Capable of handling maximum amperage ratings of one point five, three point three, and three amps
• Wall mountable, encapsulated for enhanced durability

Product Highlights

This transformer stands out for its protective features and reliable performance in demanding environments. It is ideal for harsh industrial conditions and corrosive chemical exposures. The core and coil are fully sealed to prevent moisture ingress and corrosion.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: T253007S

Technical Specifications

• Application: Harsh industrial locations, corrosive chemical exposure, wastewater treatment
• Connection Type: Wire lead
• Dimensions: Three point eighty-eight inches long x four point zero eight inches wide x eight point sixty-eight inches high
• Enclosure: NEMA 3R
• Frequency Rating: Fifty/sixty Hz
• Insulation: Class F/one hundred fifty-five degrees Celsius
• Maximum Amperage Rating: One point five/three point three/three amps
• Mounting Type: Wall
• Phase: One phase
• Power Rating: Zero point twenty-five kVA
• Secondary Voltage: One hundred twenty/two hundred forty VAC
• Temperature Rating: One hundred fifteen degrees Celsius
