Hubbell T181052 T-1-81052-ELEC .750KVA Buck And Boost

Product Description

Hubbell T181052 is a Buck Boost Transformer. It is designed with an encapsulated structure. The primary voltage is 120/240 VAC, and the secondary voltage is 12/24 VDC. This transformer has a power rating of 7.56 kVA and operates at 50/60 Hz. The unit supports one phase and has a maximum output of 62.50 A at twelve volts and 31.25 A at twenty-four volts. The transformer is suitable for wall mounting and is built with steel housing, ensuring durability.

• Power rating of 7.56 kVA
• Primary voltage of 120/240 VAC
• Compact design suitable for multiple applications

Product Highlights

This transformer is a reliable solution for adjusting line voltage. It can reduce or raise voltage by five to twenty percent, which is helpful for various devices.

Product Information

Standard Information

• Manufacturer: Hubbell
• Product SKU: 2280710

Technical Specifications

• Application: For low voltage lighting or control circuitry applications
• Connection Type: Wire Lead/Screw
• Dimensions: 4.51 inches L x 4.75 inches W x 9.68 inches H
• Enclosure: NEMA 3R
• Frequency Rating: 50/60 Hz
• Housing Material: Steel
• Insulation: Class H/180 degrees C
• Manufacturer Part Number: T181052
• Maximum Amperage Rating: 62.50 A at 12 V/31.25 A at 24 V Output
• Mounting Type: Wall
• Phase: 1 ph
• Power Rating: 7.56 kVA
• Prop65 Message: WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov
• Secondary Voltage: 12/24 VDC
• Temperature Rating: 115 degrees C
• Standards/Approvals: UL 506 File No. E79947V1|UL Control Number 50B8|UL Insulation Number X3221|CSA Certified|OSHA Approved|ANSI Specified|IEEE Certified|PROP65: Cancer and Reproductive Harm www.P65Warnings.ca.gov
• Type: Encapsulated
