Hubbell T181051 T-1-81051-ELEC TRANSFORMER 5.04 kVA Isolation Buck Boost Transformer

Product Description

Hubbell T181051 is an isolation buck boost transformer designed for low voltage applications. The transformer operates with a primary voltage of 120/240 VAC and provides a secondary voltage of 12/24 VDC. It has a power rating of 5.04 kVA and operates at a frequency of 50/60 Hz. This device can handle a maximum output of 41.6 A at 12 VAC and 20.8 A at 24 VAC.

• Encapsulated core and coil for protection
• Designed to adjust line voltage by 5 to 20 percent
• Suitable for powering motors and electrical equipment

Product Highlights

This transformer is ideal for applications requiring voltage adjustment and is well suited for HVAC systems, lighting, and control circuits.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: T181051

Technical Specifications

• Power Rating: 5.04 kVA
• Connection Type: Wire Lead/Screw
• Dimensions: 4.2 in L x 4.37 in W x 9.06 in H
• Enclosure: NEMA 3R
• Frequency: 50/60 Hz
• Insulation Class: Class H/180 deg C
• Maximum Amperage: 41.6 A at 12 V / 20.8 A at 24 V Output
• Mounting Type: Wall
• Phase: 1 ph
• Prop65 Warning: WARNING: Cancer and Reproductive Harm www.P65Warnings.ca.gov
• Secondary Voltage: 12/24 VDC
• Temperature Rating: 115 deg C
• Standards/Approvals: UL 506 | CSA Certified | OSHA Approved
