Hubbell T113075 T-1-13075 -ELEC 2KVA Buck And Boost Transformer

Product Description

The Hubbell T113075 is an encapsulated buck boost transformer suitable for various electrical applications. This transformer supports a primary voltage of 120/240 VAC and provides a secondary voltage of 16/32 VDC. It has a power rating of thirty kVA and operates at a frequency of sixty Hz. It is designed for wall mounting and features a steel housing.

• Encapsulated transformer design
• Wall mountable for easy installation
• Supports multiple voltage levels for versatile applications

Product Highlights

This transformer is ideal for low voltage lighting or control circuitry applications and enhances voltage for devices such as air-conditioning compressors.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: T113075

Technical Specifications

• Application: For low voltage lighting or control circuitry applications
• Connection Type: Wire Lead/Screw
• Dimensions: 5.13 inches L x 5.5 inches W x 13 inches H
• Enclosure: NEMA 3R
• Frequency Rating: 60 Hz
• Housing Material: Steel
• Insulation: Class H/180 degrees C
• Maximum Amperage Rating: 125 A at 16 VAC / 62.5 A at 32 VAC Output
• Mounting Type: Wall
• Phase: 1 ph
• Power Rating: 30 kVA
• Secondary Voltage: 16/32 VDC
• Temperature Rating: 115 degrees C
• Standards/Approvals: UL 506, CSA Certified, OSHA Approved
