Hubbell RR350F Hub Power Receptacle 50A 125/250V 3P3W

Product Description

The Hubbell RR350F is a Wiring Device-Kellems tradeSELECT power receptacle designed for dryer range applications. It supports one-phase power with a voltage rating of 125/250 VAC and an amperage rating of 30 A. The receptacle features three poles and three wires, conforming to NEMA 10-30R ratings.

• Flush mount design suitable for gang boxes
• Pressure screw terminals ensure secure connections
• Tamper-resistant shutter for safety compliance

Product Highlights

This receptacle is ideal for residential applications, emphasizing safe and reliable power connections for dryers.

Product Information

Standard Information

• Manufacturer: Hubbell
• MPN: RR350F

Technical Specifications

• Amperage Rating: 30 A
• Application: Residential Applications
• Color: Black
• Dimensions: 2.4 in W x 2.5 in D x 3.75 in H
• Material: Thermoplastic
• NEMA Rating: 10-30R
• Number of Poles: 3
• Number of Wires: 3
• Standards/Approvals: CSA Certified, RoHS Compliant, UL Listed
• Temperature Rating: 75 deg C
• Terminal Type: Pressure Screw
• Type: 1-Phase Dryer Range Screw Mount
• Voltage Rating: 125/250 VAC
