Product Description
The Hubbell RCD111W is a two-position standard combination switch. It operates at 120/277 VAC and has a power rating of 15 A, which translates to 4155 W. This device features a rocker actuator, threaded mounting, and side wire terminal for easy installation and reliability.
- Durable snap switch action
- Compatible with indoor dry environments
- Designed for residential applications
Product Highlights
This combination switch is built for an operating temperature range from negative twenty to sixty degrees Celsius and can withstand 30000 operating cycles, ensuring long-term use.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
MPN: RCD111W
Technical Specifications
-
Actuator: Rocker
-
Amperage Rating: 15 A
-
Application: Indoor Dry Environment and Residential Applications
-
Color: White
-
Contact Configuration: 2-Position
-
Dimensions: 1.32 in W x 1 in D x 4.2 in H
-
Environmental Conditions: -20 to 60 deg C Operating Temperature
-
Mounting: Threaded
-
Number of Poles: 1
-
Operating Cycles: 30000 Cycles
-
Power Rating: 4155 W
-
Series: Decorator
-
Standards/Approvals: RoHS Compliant, UL 20 File No. E3896, CSA Certified, NEMA WD1/WD5
-
Terminal Type: Side Wire
-
Type: 3-Way 2-Position Standard
-
Voltage Rating: 120/277 VAC
