Hubbell OLB-8CG OLB Conduit Body Type LB 3 in Replacement MPN

Product Description

The Hubbell OLB-8CG is a conduit body designed for Rigid and IMC conduit applications. This aluminum body features a three-inch hub and is powder coated for durability. It measures thirteen and fifteen-sixteenths inches long, four and three-eighths inches wide, and six and one-half inches high. Built with two hubs, it provides access for pulling and splicing conductors.

• Constructed from copper-free aluminum
• Compatible with tapered threaded hubs (NPT)
• Meets standards for hazardous location applications

Product Highlights

The OLB-8CG conduit body is designed for rugged environments. Its raintight feature works when used with gasketed covers, ensuring protection in various weather conditions. The product is ideal for industrial facilities.

Product Information

Standard Information

• Manufacturer: Hubbell
• Model Number: OLB-8CG

Technical Specifications

• Type: Type LB
• Color: Gray
• Connection Type: Thread
• Dimensions: Thirteen and fifteen-sixteenths inches L x four and three-eighths inches W x six and one-half inches H
• Finish: Powder Coated
• Hub Size: Three inches
• Material: Aluminum
• Number of Hubs: Two
• Series: O Series
• Standards/Approvals: UL File No. E3397, CSA LR11852, Federal Specification W-C-586D/A-A 50563
