Hubbell OC-2CG Killark Body, Cvr, Gask 3/4 C Aluminum

Product Description

The Hubbell OC-2CG is a conduit body designed for access to conductors for pulling, splicing, and maintenance. It features a durable aluminum construction with a powder-coated finish. This Type-C conduit body is compatible with rigid conduit and intermediate metal conduit (IMC). The unit includes two hubs for added functionality and has dimensions of six and one-eighth inches in length, one and five-eighths inches in width, and one and five-eighths inches in height.

• Two tapered threaded hubs (NPT) for efficient connection
• Crafted from copper-free aluminum for reduced corrosion
• Suitable for wet locations with gasketed cover usage

Product Highlights

The OC-2CG is part of the O Series, providing reliable access for electrical maintenance and installation. Ideal for both industrial and commercial applications.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 78393604923

Technical Specifications

• Type: Type-C
• Application: Access for pulling and splicing
• Connection Type: Tapered NPT
• Hub Size: 3/4 inch
• Material: Aluminum
• Finish: Powder Coated
• Number of Hubs: 2
• Dimensions: 6-1/8 in L x 1-5/8 in W x 1-5/8 in H
• Standards/Approvals: CSA Certified, UL Listed
