Hubbell L520C L520C HUBBELL SELECT SPEC CONNECTOR NEMA L5-20R

Product Description

The Hubbell L520C is a locking connector designed for reliable power connections. This product features a female grounding standard cord mount. It operates at one hundred twenty-five volts AC with twenty amps current rating. It's rated for two poles and three wires. Ideal for heavy-duty industrial applications.

• Operates at 125 VAC with a 20 A rating
• Compatible with cords from 0.385 to 1.15 inches in diameter
• Temperature rating from -40 to 75 degrees Celsius

Product Highlights

This connector is suitable for commercial and industrial use, providing a safe disconnect solution between equipment and power sources.

Product Information

Standard Information

• Application: Heavy Duty Industrial Applications
• Manufacturer: Hubbell

Technical Specifications

• MPN: L520C
• NEMA Rating: L5-15R
• Amperage Rating: 20 A
• Voltage Rating: 125 VAC
• Temperature Rating: -40 to 75 degrees C
• Terminal Type: Screw
• Number of Poles: 2
• Number of Wires: 3
• Cord Diameter: 0.385 to 1.15 inches
• Material: Composite
• Standards/Approvals: RoHS Compliant, CSA Certified, UL 498, NEMA WD1/WD5
