Hubbell L1620P LKG PLG, 20A 3PH480V, HUB PRO, L16-20P

Product Description

The Hubbell L1620P is a locking male plug designed for 3-phase grounding applications. It operates at 480 VAC and has a current rating of 20 A. This plug features a NEMA rating of L16-20P and includes three poles and four wires in a durable composite housing.

• Temperature rating from -40 to 60 degrees Celsius.
• Meets UL 498 standards for safety and performance.
• Suitable for indoor dry use unless protected by additional means.

Product Highlights

This locking male plug ensures reliable electrical connections and is suitable for commercial and industrial applications.

Product Information

Standard Information

• Manufacturer: Hubbell
• Manufacturer Part Number: L1620P

Technical Specifications

• Amperage Rating: 20 A
• Voltage Rating: 480 VAC
• Number of Poles: 3
• Number of Wires: 4
• Material: Composite
• NEMA Rating: L16-20P
• Terminal Type: Screw
• Standards/Approvals: RoHS Compliant, UL Listed, CSA Certified
• Application: For power connection applications
• Grade: Commercial/Industrial
• Color: Black
• Temperature Rating: -40 to 60 degrees Celsius
