Hubbell L1520R HWD Twist-Lock 250V 20A 3-Phase Grounding Standard Single Screw Mount

Product Description

The Hubbell Wiring Device-Kellems L1520R is a twist-lock receptacle designed for reliable connection in various electrical applications. This locking receptacle supports a voltage rating of two hundred fifty volts alternating current (VAC) and operates at twenty amps. It is ideal for commercial and industrial use, specifically in locations that require a secure power connection.

• Rated for three-phase power with a grounding standard.
• Constructed of durable thermoplastic material.
• Temperature range from negative forty degrees to eighty-five degrees Celsius.

Product Highlights

This receptacle is suited for industrial applications, including factory, floor equipment wiring, and portable equipment. It features screw mount terminals to accommodate 14 to 12 American wire gauge (AWG) wiring.

Product Information

Standard Information

• Brand: Hubbell Wiring Device-Kellems
• MPN: L1520R

Technical Specifications

• Amperage Rating: 20 A
• Voltage Rating: 250 VAC
• Number of Poles: 3
• Number of Wires: 4
• NEMA Rating: L15-20R
• Dimensions: 1.703 in W x 1.234 in D
• Material: Thermoplastic
• Terminal Type: Screw
• Environmental Conditions: Indoor dry unless protected by additional means
• Standards: RoHS Compliant, UL 498, CSA Certified
