Hubbell L1520P LKG PLG, 20A 3PH250V, HUB PRO, L15-20P

Product Description

The Hubbell L1520P is a Wiring Device-Kellems Twist-Lock® Locking Male Plug designed for 3-phase grounding applications. This plug offers a secure connection for power needs up to 20 Amps at 250 VAC. It features a composite body to withstand harsh conditions.

• Suitable for indoor and outdoor use when protected.
• Compatible with wires ranging from 10 to 18 AWG.
• Constructed to meet UL and CSA standards.

Product Highlights

The L1520P provides a safe disconnect solution between equipment and power sources. It features a locking interface that ensures a reliable connection.

Product Information

Standard Information

• Manufacturer: Hubbell
• Application: For power connection applications

Technical Specifications

• Amperage Rating: 20 A
• Voltage Rating: 250 VAC
• Number of Poles: 3
• Number of Wires: 4
• Temperature Rating: -40 to 60 deg C
• NEMA Rating: L15-20P
• Terminal Type: Screw
• Grade: Commercial/Industrial
• Material: Composite
• Standards/Approvals: CSA Certified, RoHS Compliant, UL Listed
