Product Description
The Hubbell L1520C is a locking connector designed for demanding electrical applications. This product features a three-phase female grounding standard cord mount, suitable for various commercial and industrial environments. It operates at a voltage of 250 VAC and has an amperage rating of 20 A.
- Compatible with 0.625 to 1.05 inches diameter cords
- Temperature rating from -40 to 75 degrees Celsius
- Meets NEMA L15-20R requirements
Product Highlights
This locking connector assures a safe disconnect solution between equipment loads and power sources with its reliable locking interface.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
MPN: L1520C
Technical Specifications
-
Application: Heavy Duty Industrial Applications
-
Amperage Rating: 20 A
-
Voltage Rating: 250 VAC
-
Number of Poles: 3
-
Number of Wires: 4
-
Temperature Rating: -40 to 75 degrees Celsius
-
NEMA Rating: L15-20R
-
Material: Composite
-
Dimensions: 1.88 in ID x 2.13 in OD
-
Cord Diameter: 0.625 to 1.05 in
-
Standards/Approvals: RoHS Compliant, CSA Certified, UL 498, NEMA WD1/WD5
