Product Description
The Hubbell KPA8CTP is a one-piece cable terminal lug designed for solid copper conductors ranging from fourteen to six AWG. This terminal lug features a #10 stud and includes a single bolt hole for secure connection. The dimensions of the tongue measure 0.38 inches in width by 0.81 inches in thickness. The KPA8CTP is made from a copper alloy and is electro-zinc plated for durability.
- Solid copper conductor use
- Electro-zinc plated for extended life
- Compatible with a range of cable sizes
Product Highlights
This terminal lug offers reliable electrical connections and easy installation without special tools. It minimizes over-torquing which may lead to conductor damage.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
Manufacturer Part Number: KPA8CTP
Technical Specifications
-
Conductor Size: 14 to 6 AWG
-
Material: Copper Alloy
-
Tongue Size: 0.38 in W x 0.81 in THK
-
Finish: Electro-Zinc Plated
-
Series: KPA-TP
-
Number of Bolt Holes: 1
-
Installation Torque: 35 in-lb
-
Standards/Approvals: RoHS Compliant, UL 468A/468B, CSA Certified
-
Dimensions: 11 in L x 0.81 in H
