Product Description
The Hubbell KPA28 is a cable terminal lug designed for use with one to four aught American Wire Gauge conductors. This terminal lug features a three eighths inch stud and one bolt hole for secure connections.
- 1 to 4/0 AWG conductor size
- Compatible with copper conductors
- Electro-zinc plated for durability
Product Highlights
The KPA28 is suitable for connecting cables to equipment pads or terminal blocks, particularly in light industrial settings.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
MPN: KPA28
Technical Specifications
-
Application: For joining a wide range of cable to equipment pads or terminal blocks, especially good in light industrial
-
Conductor Size: 1 to 4/0 AWG
-
Conductor Type: Copper
-
Dimensions: 2.29 in L x 1.66 in H
-
Finish: Electro-Zinc Plated
-
Material: Copper Alloy
-
Number of Bolt Holes: 1
-
Series: KPA
-
Specifications: Hex Head, 250 in-lb Installation Torque, (1) Screw
-
Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 468A/468B, CSA Certified
-
Stud Size: 3/8 in
-
Tongue Size: 1 in W x 0.13 in THK
-
Tongue Type: Straight
