Product Description
The Hubbell KPA25 is a cable terminal lug designed specifically for copper conductors ranging from four to one-aught AWG. It is compatible with five-sixteenth inch studs and features a single bolt hole. The lug is constructed from copper alloy and is electro-zinc plated for added durability.
- Suitable for both industrial and commercial applications.
- Easy installation with a slotted Robertson screw.
- Features a straight tongue design for efficient connection.
Product Highlights
This terminal lug is ideal for connecting cables to equipment pads or terminal blocks, providing reliable and solid connections.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
Manufacturer Part Number: KPA25
Technical Specifications
-
Application: For joining a wide range of cable to equipment pads or terminal blocks, especially good in light industrial
-
Conductor Size: 4 to 1/0 AWG
-
Conductor Type: Copper
-
Dimensions: 1.7 in L x 1.25 in H
-
Finish: Electro-Zinc Plated
-
Material: Copper Alloy
-
Number of Bolt Holes: 1
-
Series: KPA
-
Specifications: (1) Slotted Robertson Screw, 180 in-lb Installation Torque
-
Standards/Approvals: ARRA Compliant, Buy American Act Compliant, RoHS Compliant, UL 468A/468B, CSA Certified
-
Stud Size: 5/16 in
-
Tongue Size: 0.62 in W x 0.1 in THK
-
Tongue Type: Straight
