Hubbell KA6U BURNDY ALUM TERM LUG 14-6STR ALCU W/1/4STUD HOLE

Product Description

The Hubbell KA6U is a mechanical bolted lug and terminal designed for universal use with copper and stranded aluminum conductors. This dual-rated lug accommodates conductor sizes ranging from fourteen to six AWG and features a quarter-inch stud for secure attachment. It is built with high-strength aluminum alloy and is electro-zinc plated for optimal conductivity and low contact resistance.

• Suitable for both aluminum and copper conductors
• Meets various compliance standards including UL 486A and RoHS
• Designed for easy installation with a torque requirement of forty-five inch-pounds

Product Highlights

This product is ideal for electrical connections in commercial and industrial settings, providing a reliable and durable solution for connecting conductors.

Product Information

Standard Information

• Manufacturer: Hubbell
• Application: For aluminum and copper conductors

Technical Specifications

• Conductor Size: 14 to 6 AWG
• Stud Size: 1/4 inch
• Voltage Rating: 600 V
• Temperature Rating: 194 degrees Celsius
• Dimensions: 1.06 inches long x 0.5 inches high
• Series: KA-U
• Material: Aluminum
• Finish: Electro-Zinc Plated
• Number of Bolt Holes: 1
