Hubbell KA25U KA-U Dual Rated Universal Mechanical Lug 14 to 1/0 AWG 1/4 in Stud

Product Description

The Hubbell KA25U is a mechanical bolted lug and terminal. It is designed for aluminum and copper conductors, accommodating sizes from fourteen to one aught AWG. The lug features a one-quarter inch stud and one bolt hole, which makes it suitable for various electrical connections.

• Constructed from high-strength aluminum alloy
• Dual rated for aluminum and solid/stranded copper conductors
• Rated for voltages up to 600 volts

Product Highlights

This lug is designed to provide reliable connections in electrical systems.

Product Information

Standard Information

• Manufacturer: Hubbell
• Manufacturer Part Number: KA25U

Technical Specifications

• Application: For aluminum and copper conductors
• Conductor Size: 14 to 1/0 AWG, 12 to 1/0 AWG
• Conductor Type: Aluminum/Solid/Stranded Copper
• Dimensions: 1.5 in L x 0.63 in W
• Finish: Electro-TiN Coated
• Material: Aluminum
• Number of Bolt Holes: 1
• Specifications: 1-Conductor, (1) Screw
• Voltage Rating: 600 V
• Temperature Rating: 194 deg F
• Tongue Size: 0.81 in L x 0.63 in W x 0.19 in THK
• Type: Type KA-U Dual Rated Universal
