Product Description
The Hubbell HBL9452C is a straight blade power plug suitable for 125/250 volt applications. It is rated for 50 amps and features a 1-phase grounding standard design. Ideal for commercial and industrial settings, this plug provides reliable connections in various environments.
- Rated for 125/250 VAC and 50 A
- Compatible with 14-50P NEMA configurations
- Constructed with durable nylon material
Product Highlights
This plug is engineered to handle tough conditions, providing safety with IP20 enclosure, and can accommodate cord diameters from zero point six two five to one point thirty-one inches. The operational temperature range is between negative forty to seventy-five degrees Celsius.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
UPC: 78358501533
Technical Specifications
-
Amperage Rating: 50 A
-
Color: Black
-
Cord Diameter: 0.625 to 1.31 in
-
Dimensions: 4.5 x 3.38 x 2.37 in
-
Enclosure: IP20
-
Grade: Commercial/Industrial
-
Horsepower: 2 hp
-
Material: Nylon
-
NEMA Rating: 14-50P
-
Number of Poles: 3
-
Number of Wires: 4
-
Standards/Approvals: UL 498, File No. E1706 Listed, UL 94-HB Flammability Rating, CSA C22.2 No. 42, 280, NEMA WD1/WD5, RoHS Compliant
-
Temperature Rating: -40 to 75 deg C
-
Terminal Type: Screw
-
Type: 1-Phase Grounding Standard Cord Mount
-
Voltage Rating: 125/250 VAC
