Hubbell HBL5464VY HUB 2P-3W-20A-250V YLW

Product Description

The Hubbell HBL5464VY is a Valise® Straight Blade Plug designed for 1-phase grounding applications. This portable standard cord mount plug operates at 250 VAC and 20 A. It is suitable for use in dry locations and indoor applications. The plug supports a cord diameter ranging from 0.22 to 0.66 inches and can handle temperatures from -40 to 75 degrees Celsius.

• Durable composite material
• IP20 enclosure rating
• Supports 2 poles and 3 wires

Product Highlights

Designed for easy assembly, the Hubbell Valise plug offers reliable cord gripping and impact resistance while maintaining a completely insulated body for safety.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 78358501318

Technical Specifications

• Amperage Rating: 20 A
• Voltage Rating: 250 VAC
• Horsepower: 2 hp
• NEMA Rating: 6-20P
• Enclosure: IP20
• Material: Composite
• Dimensions: 1.88 x 1.5 x 1.13 inches
• Number of Wires: 3
• Temperature Rating: -40 to 75 degrees Celsius
• Standards/Approvals: UL 498, CSA C22.2, RoHS Compliant
