Hubbell HBL460R9W Locking Receptacle 60A 200-250V

Product Description

The HUBBELL HBL460R9W is a heavy-duty locking receptacle designed for three-pole, four-wire electrical distribution in industrial and commercial settings. Rated for 60 and 63 amps at 200 to 250 volts, this receptacle handles high-current loads where a secure, twist-lock connection is required to prevent accidental disconnection. Built to IP ratings consistent with NEMA 4X and IEC 69K environmental designations, it is suited for wet, dusty, or wash-down environments. Licensed electricians and industrial maintenance technicians are the primary installers of this device.

This receptacle is used in heavy industrial facilities, commercial construction sites, and process environments where three-phase or high-current single-phase power distribution panels, portable equipment connections, or temporary power assemblies require a weatherproof locking outlet. The 4X and 69K ratings make it appropriate for outdoor installations or indoor areas exposed to water spray and contaminants.

Key Features

• 60A and 63A dual-rating supports both North American and IEC load requirements
• 200 to 250 volt operating range covers common industrial supply voltages
• 3-pole, 4-wire configuration for grounded three-phase or high-current single-phase circuits
• NEMA 4X and IEC IP69K environmental ratings for wet and wash-down locations
• Twist-lock retention prevents accidental plug withdrawal under load or vibration

Compatibility

Designed as an OEM-style locking receptacle for industrial and commercial power distribution systems requiring a 3-pole, 4-wire, 60A twist-lock outlet rated for 200 to 250 volts.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize the circuit at the panel and verify zero voltage with a meter before wiring. Do not exceed the receptacle amperage rating when sizing branch circuit overcurrent protection. Enclosure knockout size and conduit fittings should be confirmed against the box configuration before mounting.

Technical Specifications

• Amperage Rating: 60A / 63A
• Voltage Rating: 200-250 volts
• Pole Configuration: 3-Pole, 4-Wire
• Environmental Rating: NEMA 4X / IEC IP69K
• UPC: 783585404936

Standard Information

• Brand: HUBBELL
• Manufacturer Part Number: HBL460R9W
