Hubbell HBL1222 HUB 20A DP BRN SW 1222AH

Product Description

The Hubbell HBL1222 is a 4-way heavy-duty toggle switch designed for general purpose use. It can handle voltages from one hundred twenty to two hundred seventy-seven volts AC and has a current rating of twenty amps. With a power rating of five thousand five hundred forty watts, this switch is suitable for various industrial applications and indoor dry environments.

• Durable nylon toggle
• Large brass binding screws
• Threaded mounting for secure installation

Product Highlights

This toggle switch features abuse-resistant design, ensuring longevity and reliability in demanding conditions.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 78358543160

Technical Specifications

• Actuator: Toggle
• Amperage Rating: 20 A
• Application: Industrial Applications and Indoor Dry Environment
• Color: Brown
• Contact Configuration: 2-Position
• Dimensions: 4.06 inches x 1.31 inches x 1.87 inches
• Environmental Conditions: -40 to 75 degrees C
• Material: Thermoset
• Mounting: Threaded
• Number of Poles: 2
• Operating Cycles: 50000 cycles
• Power Rating: 5540 W
• Standard Approvals: CSA Certified, UL94 V-2 Flammability Rating, UL 20
• Terminal Type: Back/Side Wire
• Voltage Rating: 120 to 277 VAC
