Product Description
The Hubbell DS120I is a wiring device designed for ease of use in various commercial settings. This decorator switch operates at voltage ratings from one hundred twenty to two hundred seventy-seven VAC and supports a maximum power rating of five thousand five hundred forty watts.
- Heavy duty nylon toggle is impact-resistant.
- Positive snap action for reliable contact.
- Threaded mounting allows for secure installation.
Product Highlights
This switch features a thermoplastic construction which withstands environmental temperatures ranging from negative forty to seventy-five degrees Celsius.
Product Information
Standard Information
-
Manufacturer: Hubbell
-
MPN: DS120I
Technical Specifications
-
Actuator: Rocker
-
Amperage Rating: 20 A
-
Application: Commercial Heavy Duty, General Purpose AC and Indoor Applications
-
Color: Ivory
-
Contact Configuration: 2 Position
-
Dimensions: 4.28 inches x 1.43 inches x 1.54 inches
-
Enclosure: NEMA WD-1
-
Environmental Conditions: -40 degrees Celsius to 75 degrees Celsius
-
Material: Thermoplastic
-
Mounting: Threaded
-
Number of Poles: 1
-
Operating Cycles: 50000 cycles
-
Power Rating: 5540 W
-
Standards/Approvals: RoHS Compliant, CSA Certified, UL 20, UL94 V-2 Flammability Rating
-
Terminal Type: Screw
-
Voltage Rating: 120 VAC to 277 VAC
