Hubbell BIT2/0FX BIT 3A Insulated Multi-Tap Connector 14 to 2/0 AWG

Product Description

The Hubbell BIT2/0FX is a BIT Insulated Multi-Tap Connector. It is designed for use with aluminum and copper stranded conductors sized fourteen to two/zero AWG and fourteen to one AWG. This connector can handle voltages up to six hundred VAC and operates efficiently in temperatures ranging from minus forty to one hundred thirty-five degrees Celsius.

• Two-port design with a three-sixteenths inch hex key
• Plastisol insulation for enhanced safety
• RoHS compliant and UL listed

Product Highlights

The BIT2/0FX offers a clear insulated body that helps protect against moisture and contaminants. It reduces installation costs and time, eliminating the need for taping.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 62194543920

Technical Specifications

• Type: Type 3A Bit Insulated
• Conductor Size: 14 to 2/0 AWG, 14 to 1 AWG
• Conductor Type: Aluminum/Copper/Stranded
• Voltage Rating: 600 VAC
• Temperature Rating: -40 to 135 deg C
• Dimensions: 1.52 in L x 1.31 in W x 1.38 in H
• Finish: Tin Plated
• Standards/Approvals: RoHS Compliant, UL 468A/468B
