Hubbell BISR1/0FX BURNDY 1/0-14, In-Line Splice, Flex

Product Description

The Hubbell BISR1/0FX is a BURNDY UNITAP Splice Reducer designed for in-line splicing. This effective connector works for aluminum and copper conductors ranging from 14 to 1/0 AWG. The product is suitable for quick and easy connections, ensuring reliability in electrical systems.

• 2-Port Type BIBS in-line insulated splice
• Compatible with aluminum, copper, and stranded conductors
• Insulation rated for up to 135 degrees Celsius

Product Highlights

This splice reducer is built to simplify connections and reduce installation time.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 62194543997

Technical Specifications

• Conductor Size: 14 to 1/0 AWG
• Voltage Rating: 600 VAC
• Temperature Rating: 135 degrees Celsius
• Dimensions: 2.91 in L x 0.91 in W x 1.38 in H
• Material: Aluminum, Tin Plated
• Finish: Tin Plated
• Application: For tap connections and in-line splice/reductions
• Specifications: 3/16 in Hex Key, Plastisol Insulation
• Standards/Approvals: RoHS Compliant, UL 468A/468B, PROP65 warning for lead exposure
