Hubbell AMS500 AMS-500 BURNDY SPLICE 3/0-500 2SCR

Product Description

The Hubbell AMS500 is a dual rated non-insulated mechanical splicer and reducer connector. This connector accommodates copper and aluminum conductors ranging from three-aught AWG to five hundred kcmil. It features four screws for secure connections. This product is designed for high-performance applications in various electrical installations.

• Dual rated for use with aluminum and copper conductors
• Constructed from high-strength aluminum
• Includes four screws for reliable connectivity

Product Highlights

This splicer is suitable for applications involving solid or stranded aluminum and copper conductors. It ensures low contact resistance and prevents galvanic corrosion due to its tin plating.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 78181024105

Technical Specifications

• Application: For copper and aluminum conductors
• Conductor Size: 3/0 AWG to 500 kcmil
• Conductor Type: Solid/Stranded Aluminum/Copper
• Dimensions: 4.7812 in L x 1.25 in W x 1.48 in H
• Finish: Tin Plated
• Number of Screws: 4
• Temperature Rating: 194 deg F
• Standards/Approvals: ANSI C119.4, ARRA Compliant, Buy American Act Compliant, CSA Certified, RoHS Compliant, UL 467, PROP65: This product can expose you to chemicals including lead and lead compounds, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
