Hubbell 9650NC Nema 6-50P Rubber Plug 50A 250V

Product Description

The HUBBELL 9650NC is a NEMA 6-50P straight blade rubber plug rated for 50-amp, 250-volt applications. Built with a rubber construction for durability and flexibility, it provides a reliable connection point for high-draw equipment requiring a grounded two-pole, three-wire configuration. This plug is installed by licensed electricians on the cord end of equipment that demands a robust, weather-resistant termination point. The rubber body resists cracking and abrasion under regular service conditions, making it well suited to demanding job site and industrial environments.

The 9650NC is typically used in commercial and industrial settings where 250-volt, 50-amp circuits power welding equipment, large power tools, EV charging equipment, or other high-demand loads. The NEMA 6-50P configuration matches the standard 6-50R receptacle found on dedicated 240-volt circuits. It is appropriate for both permanent installations and cord-and-plug connected equipment where a rugged, field-assembled plug is required.

Key Features

• NEMA 6-50P straight blade configuration for 250-volt, 50-amp grounded circuits
• Rubber construction provides flexibility and resistance to abrasion and impact
• Two-pole, three-wire grounded design for safe high-current cord termination
• Field-wireable plug suitable for cord-end assembly by qualified electricians

Compatibility

Designed as an OEM-style field-wireable cord plug for use with NEMA 6-50R receptacles on dedicated 250-volt, 50-amp circuits.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize the circuit completely before assembling or disassembling any cord-end plug. Ensure conductors are terminated to the correct terminals per the plug body markings and that the strain relief is properly secured to prevent pull-out of the cord. Verify the cord gauge is rated for the circuit ampacity before assembly.

Technical Specifications

• NEMA Configuration: 6-50P
• Amperage: 50 amps
• Voltage: 250 volts
• Wiring: 2-pole, 3-wire grounded
• Body Material: Rubber
• UPC: 78178673225

Standard Information

• Brand: HUBBELL
• Manufacturer Part Number: 9650NC
