Hubbell 5197-0 Weatherproof Cluster Cover 4-1/8 in Dia

Product Description

The HUBBELL 5197-0 is a weatherproof cluster cover with a 4-1/8 inch diameter, constructed from die-cast aluminum. It provides a means of mounting lampholders and other accessories. Designed for use with BELL single gang or round weatherproof boxes and electrical applications. Includes installation hardware, gasket, and multi-lingual instructions.

• Rugged die cast construction
• State of the art powder coat finish provides maximum weatherability and scratch resistance
• NEMA 3R rated

Product Highlights

This weatherproof cluster cover is ideal for outdoor lighting and electrical connections, ensuring durability and protection in harsh weather conditions.

Product Information

Standard Information

• Brand: HUBBELL
• Manufacturer Part Number: 5197-0
• Country of Origin: India

Technical Specifications

• Diameter: 4-1/8 in
• Material: Die Cast Aluminum
• Includes: Installation Hardware, Gasket, Multi-Lingual Instructions, Stainless Steel Mounting Screws, (2) Closure Plugs
• Certification: CSA Certified, UL Listed
• Outlet: 3-1/2 in
• Application: For Bell Round Weatherproof Boxes, For wet locations
• Holes: Three 1/2" NPT holes
• Color: Gray
• Coating: State-of-the-Art Powder Coated
• Depth: 1.094 in
• Finish: Powder Coated
• Knockout Size: 1/2 in
• Length: 4-1/8 in
• Mounting Type: Screw
• Number of Outlets: 3
• Shape: Round
• Standards/Approvals: UL 514A|UL Recognized|CSA C22.2 No. 18|PROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
• Type: Cluster
• Width: 4-1/8 in
• NEMA Rating: NEMA 3R rated
• Model Name: 5197-0
• Part Number: 5197-0
• Box Cover Type: Lampholder
• Color Family: Gray
• Actual Depth: 1.094 in
• Cubic Capacity: 20.03445 cu.in
• Package Height: 4.125 in
• Package Length: 1.094 in
• Package Weight: 0.34 lb
• Package Width: 4.125 in
• Certified Listed: UL Listed CSA Certified
• Industry Standard(s): UL 514A
