Hubbell 3202DB RACO DOUBLE BITE FLEX CONN 90 1/2 IN INS IRN

Product Description

The Hubbell 3202DB RACO Double Bite Flex Connector is designed for applications in dry locations. It is a 90-degree connector with a half-inch trade size. This product connects flexible metal conduits, MCI, MCI-A, and AC cables to a box or electrical enclosure. The connector is made from malleable iron and steel and is zinc plated to resist corrosion.

• Threaded mounting for stability
• Compatible with various conduit types
• Insulated throat for maximum wire protection

Product Highlights

This connector provides reliable mechanical protection for raceways and ensures secure connections.

Product Information

Standard Information

• Manufacturer: Hubbell
• UPC: 05016963202

Technical Specifications

• Application: Used in dry locations to connect flexible metal conduit, MCI, MCI-A and AC cable to a box or enclosure
• Color: Silver
• Dimensions: 2-1/4 inches in length
• Finish: Zinc Plated
• Manufacturer Part Number: 3202DB
• Material: Malleable Iron/Steel
• Mounting Type: Threaded
• Standards/Approvals: UL 514B File No. E195968, cULus Listed, NEMA FB-1
• Trade Size: 1/2 inches
• Type: Double Bite Insulated Throat
