HTPG RL6A066ADAAL Evaporator Coil Walk-In

Product Description

The HTPG RL6A066ADAAL is an evaporator coil designed for walk-in coolers. It delivers six thousand six hundred BTU of cooling capacity and is equipped with an ECM motor for effective operation. This coil runs on one hundred twenty volts alternating current and supports air defrost functionality.

• Designed for walk-in cooler applications.
• Features an ECM motor for efficient operation.
• Includes TXV, liquid line solenoid, and thermostat for temperature management.

Product Highlights

This coil is compatible with R404A refrigerant. Its low-profile design allows for versatile application in various configurations of walk-in coolers.

Product Information

Standard Information

• Cooling Capacity: 6600 BTU
• Voltage: 115V

Technical Specifications

• Airflow: 775 CFM
• Electrical: 115-1-60
• Fan Quantity: 1
• Frequency: 60Hz
• Height: 15.5 inches
• Length: 27.125 inches
• Liquid Line Size: 3/8 inches
• Motor Type: ECM
• Phase: Single
• Style: Low Profile
• Suction Line Size: 5/8 inches
• Type: Air Defrost
• Width: 18.125 inches
