HPS SP250ACP HPS SP250ACP Control Transformer 250 VA 480/600 VAC Primary 120/240 VAC Secondary

Product Description

The HPS SP250ACP Control Transformer is designed for general-purpose and industrial applications. This dry type transformer operates with a primary voltage of 480/600 VAC and a secondary voltage of 120/240 VAC. It is suitable for light duty loads and comes with a power rating of 250 VA. The transformer has a rugged design to ensure reliable operation in various conditions.

• Designed for efficient operation in light duty applications.
• Compact dimensions: 3.78 inches long, 4.09 inches wide, and 3.4 inches high.
• Easy panel mounting with screw connections.

Product Highlights

The HPS SP250ACP is ideal for applications where high inrush is not required. It provides reliable voltage transformation with ease of installation and maintenance.

Product Information

Standard Information

• Brand: HPS
• Manufacturer: Hammond Power Solutions

Technical Specifications

• Connection Type: Screw
• Dimensions: 3.78 inches L x 4.09 inches W x 3.4 inches H
• Enclosure Type: Open/Core and Coil
• Insulation: 130 deg C
• Maximum Amperage Rating: 2.08/1.04 A
• Mounting Type: Panel
• Series: Spartan
• Temperature Rating: 40 deg C
• Type: Dry Type
• Primary Voltage: 480/600 VAC
• Secondary Voltage: 120/240 VAC
• Power Rating: 250 VA
• Frequency Rating: 60 Hz
• Phase: 1 ph
