HPS C1F003LES 3 kVA Single Phase Transformer

Product Description

The HPS C1F003LES is a single-phase transformer with a power rating of 3 kVA. This transformer operates at a maximum frequency of 60 Hz. It supports primary voltage ratings of 120/240 V AC and secondary voltage ratings of 240/480 V AC. It is designed with a bracket mount and features wire lead termination.

• Power Rating: 3 kVA
• Primary Voltage: 120/240 V AC
• Secondary Voltage: 240/480 V AC

Product Highlights

The transformer is suitable for various applications where single-phase power supply is needed. It is reliable and efficient for electrical installations, providing stable voltage transformation.

Product Information

Standard Information

• Brand: HPS
• Type: Power Transformer

Technical Specifications

• Power Rating: 3 kVA
• Primary Voltage Rating (AC): 120/240 V
• Secondary Voltage Rating (AC): 240/480 V
• Termination Style: Wire Lead
• Primary Current Rating: 25 A
• Secondary Current Rating: 25 A
• Turns Ratio: 2:40
• Mounting Style: Bracket Mount
• Number of Phases: 1
• Maximum Operating Frequency: 60 Hz
