Hotpoint AHHS12E3XXA PTAC Heat Pump Unit with Electric Heat Backup 12,000 BTU, 265V, 20amp

Product Description

The Hotpoint AHHS12E3XXA PTAC heat pump unit features electric heat backup, 12,000 BTU, 265V, and 20amp. This unit includes 2 fan speeds and 4 temperature-limiting options. It also features an auto-dimming display and slinger ring condensate removal. Additional features include a coverless control panel, automatic emergency heat, and freeze/frost & overheat protection.

• 2 Fan Speeds
• 4 Temperature-Limiting Options
• Auto Dimming Display
• Slinger Ring Condensate Removal

Product Highlights

PTAC heat pump with electric heat backup, auto dimming display, and freeze/frost protection.

Product Information

Standard Information

• Brand: HOTPOINT
• Manufacturer Part Number: AHHS12E3XXA

Technical Specifications

• Control Type: Electronic
• Product Type: Packaged Terminal Air Conditioners (PTAC)
• Refrigerant Type: R32
• Temperature Range: 62 - 80 F
• Fan Speed Selections: 2 Cooling 2 Fan Only 2 Heating
• Unit Features: Auto Power Recovery Automatic Emergency Heat Automatic Indoor Frost Control Freeze Sentinel Heat Pump with Resistance Heat Backup Remote Thermostat Compatibility (Accessory Kit Required)
• Chassis Type: Slide-In
• Heat - Cool: Yes
• Heat Pump: Yes
• Heating - Reverse Cycle - COP: 3.1
• Manual Vent Control: Hidden
• Outdoor Vent / Exhaust: Yes
• Rotary Compressor: Yes
• Venting Features: Concealed Manual Vent Control
• SmartFan" Fan Cycle: Yes
• Discharge Grille: 2-position
• Fan Motor: 1
• Heating System: Heat Pump with Resistance Backup
• Cooling EER (BTUH / Watt): 10.4
• Heating - Reverse Cycle - BTUH: 11,000
• Cooling BTUH (MAX): 12200.0 Btu
• Installation: Through-the-Wall
• Cooling - Watts: 1170
• Cooling - Amperes: 4.5
• Voltage (MAX): 265.0 V
• Heat Pump - Amps: 5.2
• Heat Pump - Watts: 1035
• Manufacturer: Hotpoint
• Manufacturer Sku: AHHS12E3XXA
• Condition: New
• Cooling BTU: 12,000 BTU
• Machine Volts: 265/277 commercial
• Machine Amps: 20 amp
• Cord Included: No
• Controls: Electronic
• Heat: Heat Pump
• Heater Size (KW): 3.5 KW
• Fits Standard 42" x 16" Sleeve: Yes
• Automatic Restart: Yes
• Seacoast Protection: No
• Freeze Protection: Yes
• Fan Speeds: 3
• ADA Compliant: No
• Energy Efficiency Rating (EER): 10.4
• COP Rating: 3.1
• Sleeve Included: No
• Exterior Grille Included: No
• Maximum Cooling Watts: 1170
• Front Cover Included: Yes
• Maximum Cooling Amps: 4.5
• Actual Cooling BTUs @ 265V: 12200
• 4Less California Compliance: Yes
• Accessories: 3495|4469
