Product Description
The HOTPOINT AHES09D2XXA PTAC with Electric Heat delivers 9,000 BTU and operates at 230/208V with a 15amp requirement. It features two fan speeds and four temperature-limiting options. Equipped with auto-dimming display and slinger ring condensate removal, this unit also includes freeze/frost and overheat protection. The PTAC offers self-diagnostics and a constant fan button for user convenience.
- Features 2 fan speeds and 4 temperature-limiting options.
- Includes automatic emergency heat and auto power recovery.
- Offers freeze/frost and overheat protection for reliable operation.
Product Highlights
This PTAC unit provides efficient heating and cooling with user-friendly features and robust protection mechanisms.
Product Information
Standard Information
-
Brand: HOTPOINT
-
Manufacturer Part Number: AHES09D2XXA
Technical Specifications
-
Control Type: Electronic
-
Product Type: Packaged Terminal Air Conditioners (PTAC)
-
Refrigerant Type: R32
-
Temperature Range: 62 - 80 F
-
Fan Speed Selections: 2 Cooling, 2 Fan Only, 2 Heating
-
Unit Features: Auto Power Recovery, Automatic Indoor Frost Control, Freeze Sentinel, Power Cord (LCDI) included, Remote Thermostat Compatibility (Accessory Kit Required)
-
Auto Power Recovery: Yes
-
Chassis Type: Slide-In
-
Heat - Cool: Yes
-
Manual Vent Control: Hidden
-
Outdoor Vent / Exhaust: Yes
-
Rotary Compressor: Yes
-
Venting Features: Concealed Manual Vent Control
-
SmartFan" Fan Cycle: Yes
-
Discharge Grille: 2-position
-
Fan Motor: 1
-
Heating System: Electric Resistance
-
Cooling EER (BTUH / Watt): 11.3/11.4
-
Cooling BTUH (MAX): 9400.0 Btu
-
Cooling BTUH (MIN): 9200.0 Btu
-
Installation: Through-the-Wall
-
Overall Depth: 20 9/10 in
-
Overall Height: 16 in
-
Overall Width: 42 2/5 in
-
Net Weight: 84 lb
-
Heating - Electric - Heater Watts: 2500
-
Cooling - Watts: 830/805
-
Cooling - Amperes: 4.0/3.8
-
Voltage (MAX): 230.0 V
-
Voltage (MIN): 208.0 V
-
BTU Cooling: 9000
-
Electric Heat Capacity: 2.5 kW
-
Moisture Removal: 1.86 Pints/Hour
-
EER: 11.3
-
Cooling Area: 400 Sq. Ft.
-
Frequency: 60 Hz
-
Electrical Phases: 1
-
Amperage: 4 A
-
Recommended Breaker Size: 15 A
-
BTU Heating: 8530
-
Cooling Power Input: 500
-
Fan Speeds: 2
-
Heating BTU Capacity: 8530
-
Nominal Cooling Capacity: 9400
-
Plug Type: LCDI
