Honeywell ZD10X10TZ/U Zone Control Dampers Power 10 x 10

Product Description

The Honeywell ZD10X10TZ/U is a zone control damper designed to manage air circulation in HVAC systems. This model features a power close and spring open mechanism, ensuring efficient operation. It is compatible with TrueZONE systems and other electronic zoning systems.

• 24V spring-return motor
• Kevlar gearing enhances durability
• Adjustable range stops

Product Highlights

This zone damper utilizes a solid aluminum construction and has been designed for low leakage performance.

Product Information

Standard Information

• Size: 10 x 10 inches
• Material: Aluminum
• Vendor: Honeywell

Technical Specifications

• Power Mechanism: Power close, spring open
• Motor Type: 24V spring-return
• Compatible Systems: TrueZONE and electronic zoning
• Design Feature: Adjustable range stops
• Material Construction: Extruded aluminum frame and blades
• Leakage Rating: Low leakage performance
• Installation Type: 2-wire installation
• Orientation: Can be installed in any position
