Honeywell VRN2H7PX6100 Pressure Independent Control Valve Assembly

Product Description

The Honeywell VRN2H7PX6100 is a pressure independent control valve assembly designed for hydronic systems. It ensures a constant flow of hot or chilled water, accommodating up to 50% glycol solutions in closed-loop HVAC setups despite pressure changes. This valve features an integrated pressure control cartridge, which allows for flow balancing and regulation.

• Compatible with NPT connections from half an inch to three inches.
• Regulates water and glycol solutions efficiently.
• Equipped with a differential pressure regulator for stable pressure drop.

Product Highlights

The valve is crafted from forged brass and features NPT connections. It is suitable for a variety of temperature ranges and fluid types, making it ideal for both commercial and industrial applications.

Product Information

Standard Information

• Brand: Honeywell
• MPN: VRN2H7PX6100

Technical Specifications

• Type: Assembly
• Connection: NPT
• Pattern: 2-way
• Size: 3 inches
• GPM: 80 GPM
• Control Signal: Analog, Floating
• Valve Type: Dynamic Pressure Regulated Control Valve
• Body Style: 2-Way ball valve, straight-through flow, full port
• Body Pressure Rating: 360 psi at 250°F
• Controlled Medium: Water or Glycol solutions up to 50%
• Medium Temperature Range: -22°F to 250°F
• Close-off Pressure: 100 PSID
• Flow Characteristics: Equal percentage with flow control insert
• Body Material: Forged brass (ASTM B283)
• Flow Optimizer: Laser-milled, glass-reinforced Noryl
• Trim Material: Nickel-chrome plated brass or stainless steel
• Stem Seals: EPDM O-ring and Teflon bearings
• Ball Seals: Reinforced Teflon seals, with EPDM O-rings
• Regulator: Hydrogenated acrylonitrile-butadiene rubber rolling diaphragm
• Minimum Torque Required: 35 lb-in
• Compatible Actuators: Various models including ML6161 and MS6105
