Honeywell VRN2H6SX7100 Pressure Independent Control Valve Assembly

Product Description

The Honeywell VRN2H6SX7100 is a pressure independent control valve assembly designed specifically for HVAC systems. This valve ensures a constant flow of hot or chilled water in closed-loop systems, even with pressure changes. It facilitates the automatic management of flow and temperature in hydronic circuits, effectively maintaining the desired temperature throughout the system.

• Valve size is three inches with female NPT connections.
• Suitable for water or glycol solutions with up to fifty percent concentration.
• Constructed with stainless steel trim for durability.

Product Highlights

This valve assembly features a differential pressure regulator that simplifies system balancing, making it ideal for seamless operation in hydronic systems.

Product Information

Standard Information

• Brand: HONEYWELL
• MPN: VRN2H6SX7100

Technical Specifications

• Type: Valve Only
• Connection: NPT
• Size: 3 inches
• GPM: 75 GPM
• Valve Type: Dynamic Pressure Regulated Control Valve
• Pattern: 2-way
• Trim Material: Stainless Steel
• Body Style: Two-way ball valve, straight-through flow, full port with patented flow control insert
• Body Pressure Rating: 360 psi at 250°F
• Controlled Medium: Water or Glycol solutions up to 50%; not suitable for combustible gases
• Medium Temperature Range: -22°C to 250°F
• Maximum Differential Pressure: 1 gpm (1/2inch valve) to 95 gpm (3inch valve)
• Close-off Pressure: 100 psid
• Flow Characteristics: Equal percentage with flow control insert
• Body: Forged brass (ASTM B283)
• Flow Optimizer: Laser-milled, glass-reinforced Noryl
• Trim: Nickel-chrome plated brass or stainless steel
• Stem Seals: EPDM O-ring and Teflon bearings
• Ball Seals: Reinforced Teflon seals with EPDM O-rings
• Regulator: Hydrogenated acrylonitrile-butadiene rubber rolling diaphragm in stainless steel housing
• Compatible Actuators: Various models including ML6161, MS6105
• Minimum Torque Required: 35 lb-in up to 3 inches
• Warranty: 1 year on valves, 5 years on actuators
