Honeywell VRN2G5SX9102 Dynamic Pressure Regulated Control Valve

Product Description

The Honeywell VRN2G5SX9102 is a dynamic pressure regulated control valve designed for flow and temperature control in hydronic systems. This two-way valve maintains consistent temperature despite fluctuations in piping pressure. The integrated pressure control cartridge allows for effective flow balancing. It is suitable for use with water or glycol solutions up to fifty percent.

• Sizes range from half inch to three inches with female NPT connections
• Maintains constant pressure drop across the valve seat
• Features patented flow control with equal percentage characteristics

Product Highlights

This control valve is ideal for maintaining efficient operation in hydronic heating and cooling systems.

Product Information

Standard Information

• Brand: Honeywell
• Manufacturer Part Number: VRN2G5SX9102

Technical Specifications

• Valve Type: Dynamic Pressure Regulated Control Valve
• Connection: NPT
• Pattern: 2-way
• Size: 2.5 inches
• GPM: 70 GPM
• Body Style: Two-way ball valve, straight-through flow
• Maximum Pressure Rating: 360 psi at two hundred fifty degrees Fahrenheit
• Controlled Medium: Water or glycol solutions
• Temperature Range: -22 degrees Celsius to two hundred fifty degrees Fahrenheit
• Maximum Differential Pressure: 1 GPM to 95 GPM
• Close-off Pressure: 100 psid
• Flow Characteristics: Equal percentage with flow control insert
• Body: Forged brass
• Compatible Actuators: Includes several models for non-spring and spring return
• Minimum Torque Required: Ranges from 18 lb-in to 35 lb-in
• Warranty: 1 year on valves, 5 years on actuators
