Honeywell VRN2EQSX7100 Pressure Independent Control Valve

Product Description

The Honeywell VRN2EQSX7100 is a pressure independent control valve designed for hydronic systems. This valve uses an electric actuator to maintain temperature by adjusting flow rates when there are changes in piping pressures. It includes a built-in pressure control cartridge for effective flow balancing. This valve is compatible with hot or chilled water and can handle up to fifty percent glycol solutions.

• Connection size: one and one-half inches NPT
• Trim material: stainless steel
• Dynamic pressure regulation for consistent temperature control

Product Highlights

The Honeywell VRN2EQSX7100 offers reliable performance in various hydronic applications.

Product Information

Standard Information

• Manufacturer Part Number: VRN2EQSX7100
• Type: Assembly

Technical Specifications

• Connection: NPT
• Trim Material: Stainless Steel
• Pattern: Two-way
• Size: One and one-half inches
• GPM: Twenty-five GPM
• Control Signal: Two Position
• Valve Type: Dynamic Pressure Regulated Control Valve
• Body Style: Two-way ball valve, straight-through flow, full port
• Pipe Size: One-half inch to three inches with female NPT fittings
• Body Pressure Rating: Three hundred sixty psi at two hundred fifty degrees Fahrenheit
• Controlled Medium: Water or glycol solutions up to fifty percent
• Medium Temperature Range: Negative twenty-two degrees Celsius to two hundred fifty degrees Fahrenheit
• Maximum Differential Pressure: One GPM to ninety-five GPM
• Close-off pressure: One hundred psid
• Body: Forged brass
• Flow Optimizer: Laser-milled, glass-reinforced Noryl
• Stem Seals: EPDM O-ring and Teflon bearings
• Regulator: Hydrogenated acrylonitrile-butadiene rubber diaphragm
• Compatible Actuators: Non-spring return and spring return options available
• Minimum Torque Required: Thirty-five lb-in up to three inches
• Warranty: One year on valves, five years on actuators
