HONEYWELL VRN2DNSX6102 Pressure Independent Control Valve

Product Description

The Honeywell VRN2DNSX6102 is a pressure-regulated control valve designed for hydronic systems. This valve manages flow and temperature control through integrated technology. It ensures consistent temperature maintenance during pressure changes. The valve pairs well with Honeywell direct-coupled actuators and is engineered for versatility, suitable for hot or chilled water and glycol solutions up to fifty percent concentration.

• Sizes range from one half inch to three inches with internal NPT connections.
• Features a differential pressure regulator for maintaining a consistent pressure drop.
• Utilizes equal percentage flow characteristics for optimal performance using a patented ball insert.

Product Highlights

Product Information

Standard Information

• Brand: Honeywell
• MPN: VRN2DNSX6102

Technical Specifications

• Valve Type: Dynamic Pressure Regulated Control Valve
• Connection: NPT
• Size: One and one quarter inch
• Pattern: Two-way
• Maximum Flow Rate: Fifteen GPM
• Input Voltage: Twenty-four VAC
• Body Style: Two-way ball valve, straight-through flow
• Maximum Pressure Rating: Three hundred sixty psi
• Medium: Water or Glycol solutions up to fifty percent
• Temperature Range: Negative twenty-two degrees Celsius to two hundred fifty degrees Fahrenheit
• Flow Characteristics: Equal percentage with flow control insert
• Body Material: Forged brass
• Compatible Actuators: Various non-spring and spring return models
• Warranty: One year on valves, five years on actuators
