Honeywell VRN2CFPXB200 Pressure Independent Control Valve

Product Description

The Honeywell VRN2CFPXB200 is a pressure independent control valve designed for efficient flow management. This valve features a one-inch NPT connection and a two-way valve pattern suitable for various HVAC applications. It supports a flow rate of four GPM and operates on twenty-four volts AC, making it a reliable choice for system integration. The valve's design includes a fail-safe closed configuration and a modulating floating control function.

• One-inch NPT connection
• Operates at four GPM flow rate
• Integrated flow and temperature control

Product Highlights

The Honeywell VRN2CFPXB200 combines advanced control features with a durable design, providing effective temperature and flow regulation.

Product Information

Standard Information

• Manufacturer: Honeywell
• Type: Assembly

Technical Specifications

• MPN: VRN2CFPXB200
• Connection: NPT
• Supply Voltage (Nominal): 24 VAC
• Trim Material: Stainless Steel
• Pattern: 2-way
• Size: 1 inch
• GPM: 4 GPM
• Control Signal: Analog, Floating
• Valve Type: Dynamic Pressure Regulated Control Valve
• Pipe Size: 1/2 inch to 3 inch with female NPT pipe fittings
• Body Pressure Rating (Maximum): 360 psi at 250°F (121°C)
• Controlled Medium: Water or Glycol solutions up to 50%
• Medium Temperature Range: -22°C to 250°F
• Maximum Differential Pressure: 1 GPM for 1/2 inch valve to 95 GPM for 3 inch valve
• Close-off Pressure: 100 psid
• Flow Characteristics: Equal percentage with flow control insert
• Body: Forged brass
• Flow Optimizer: Laser-milled, glass-reinforced Noryl
• Trim (Ball and Stem): Nickel-chrome plated brass or stainless steel
• Stem Seals: EPDM O-ring and Teflon bearings
• Ball Seals: Reinforced Teflon seals with EPDM O-rings
• Regulator: Hydrogenated acrylonitrile-butadiene rubber rolling diaphragm in stainless steel housing
• Compatible Actuators: Various models including ML6161, ML7161
• Minimum Torque Required: 35 lb-in up to 3 inch
• Weight: 7 lbs
