Honeywell VRN2CBSX6100 Pressure Independent Control Valve Assembly

Product Description

The Honeywell VRN2CBSX6100 is a pressure-regulated control valve assembly ideal for hydronic systems. It automatically adjusts flow to sustain set temperatures during pressure changes, thus enhancing system efficiency. The integrated pressure control cartridge ensures balanced flow and easy management of hot or chilled water, including up to 50% glycol mixtures.

• Fits pipe sizes from 1/2 inches to 3 inches with NPT connections
• Features consistent differential pressure regulation for reliable performance
• Designed for use with Honeywell direct-coupled actuators

Product Highlights

The VRN2CBSX6100 supports water and glycol solutions, making it versatile for various applications.

Product Information

Standard Information

• Manufacturer: Honeywell
• MPN: VRN2CBSX6100

Technical Specifications

• Type: Control Valve Assembly
• Connection: NPT
• Pattern: 2-way
• GPM: 1 GPM
• Trim Material: Stainless Steel
• Control Signal: Analog, Floating
• Valve Type: Dynamic Pressure Regulated Control Valve
• Body Style: Two-way ball valve, straight-through flow, full port with patented flow control insert
• Pipe Size: 1/2 inches to 3 inches with female NPT fittings
• Body Pressure Rating (maximum): 360 psi at 250°F
• Controlled Medium: Water or glycol solutions up to 50%
• Medium Temperature Range: -22°C to 250°F
• Maximum Differential Pressure: 1 GPM to 95 GPM based on valve size
• Close-off Pressure: 100 psid
• Flow Characteristics: Equal percentage with flow control insert
• Body: Forged brass
• Flow Optimizer: Laser-milled, glass-reinforced Noryl
• Trim (ball and stem): Nickel-chrome plated brass or stainless steel
• Stem Seals: EPDM O-ring and Teflon bearings
• Ball Seals: Reinforced Teflon seals with EPDM O-rings
• Regulator: Hydrogenated acrylonitrile-butadiene rubber rolling diaphragm
• Minimum Torque Required: 35 lb-in up to 3 inches
• Compatible Actuators: Multiple Honeywell models available
• Warranty: 1 year on valves, 5 years on actuators
