Honeywell VN8ZZA00TFL VN Series Zone Valve Replacement Actuator

Product Description

The Honeywell VN8ZZA00TFL is a replacement actuator for VN Series Zone Valve assemblies. This actuator supports modulating and 2-Position configurations with voltages of 24Vac/dc, 220Vac, and 110Vac. Some models include position feedback options for enhanced control.

• Designed for VN Series Zone Valve assemblies
• Features IP54 rated enclosure
• Provides Class II electric shock protection

Product Highlights

This actuator ensures reliable operation with fail-in-place capabilities and electronic fail-safe options.

Product Information

Standard Information

• Certifications: UL/cUL, UL 60730-1, UL 60730-2-14, CSA E60730-1:15, CSA E60730-2-14
• Model: VN3ZZA00T0L, VN3ZZA00TEL, VN3ZZA00TFL, VN8ZZA00T0L, VN8ZZA00TEL, VN8ZZA00TFL, VN8ZZB00T0L, VN8ZZB00TEL, VN8ZZB00TFL, VN8ZZC00T0L

Technical Specifications

• Open/Close Time: Less than 40 seconds
• E-Fail Safe Time: Maximum 45 seconds
• Enclosure Rating: IP54
• Electric Shock Protection: Class II
