HONEYWELL VGF32EM60 3-Way Mixing Flange Globe Valve

Product Description

The HONEYWELL VGF32EM60 is a 3-way mixing globe valve designed for flanged connections. This valve features a cast iron body and stainless steel components, making it suitable for steam, hot water, or chilled water-glycol solutions with up to fifty percent concentrations. It is built to maintain a constant total flow during full plug travel while providing equal percentage flow characteristics. The valve operates optimally in temperatures ranging from thirty-five degrees Fahrenheit to one hundred thirty degrees Fahrenheit.

• ANSI Class 125 and Class 250 cast iron body with flanged end connections.
• Compliant with ANSI/ISA S7503 standards for face-to-face flange dimensions.
• Perfect for mixing applications.

Product Highlights

This valve is ideal for applications requiring precise control of fluids through mixing, ensuring efficiency in energy and resource management.

Product Information

Standard Information

• Manufacturer Part Number: VGF32EM60
• Valve Type: 3-Way

Technical Specifications

• Connection: Flange
• Size: Six inches
• Cv: 400 CV
• Trim Material: Stainless Steel
• Service: Steam, Hot Water, Or Chilled Water-Glycol Solutions Up To 50% Concentrations
• Flow Characteristic: Equal Percentage
• Operating Temperature: Thirty-five degrees Fahrenheit To One hundred thirty degrees Fahrenheit
• Close-Off Pressure: Thirteen psi
