HONEYWELL VGF21LS40 4 inch Flanged Globe Valve ANSI 125 CV=160

Product Description

The Honeywell VGF21LS40 4 inch Flanged Globe Valve is an essential component in HVAC systems, facilitating efficient 2-position or modulating control of steam, hot water, and chilled water-glycol solutions up to 50 percent. Its robust cast iron construction and stainless steel trim ensure longevity and corrosion resistance.

• ANSI Class 125 certification for reliable performance.
• Supports various actuators including electric, pneumatic, and direct-coupled types.
• Designed for easy installation and maintenance.

Product Highlights

The valve features flanged end connections and offers linear flow characteristics, accommodating a wide range of applications from 2-1/2 to 6 inches. Its self-adjusting packing and universal bonnet support various mounting configurations, enhancing its versatility.

Product Information

Standard Information

• Brand: Honeywell
• MPN: VGF21LS40

Technical Specifications

• Pressure Rating: ANSI Class 125
• Max Temperature: 353°F
• Connection Type: Flanged
• Body Material: Cast Iron
• Valve Size: 4 inches
• Flow Capacity: CV=160
