HONEYWELL VGF21ES40 ANSI 125 2-WAY 4 FLGD GLOBE VALVE 150 CV

Product Description

The Honeywell VGF21ES40 is a robust flanged globe valve designed for efficient fluid control within HVAC systems. This valve facilitates the modulation or two-position control of steam, hot water, or chilled water-glycol solutions, making it a pivotal component in heating and air conditioning systems.

• Pressure class 125/150 with a 175 psi rating.
• Constructed from durable cast iron with stainless steel trim.
• Compatible with a variety of actuators including electric, pneumatic, and Modutrol motors.

Product Highlights

Equipped with ANSI Class 125 and 250 cast iron bodies, the Honeywell VGF21ES40 ensures durability and reliable performance under varying conditions. Its design adheres to ANSI/ISA S75.03 standards for face-to-face flange dimensions, providing ease of installation across standardized systems.

Product Information

Standard Information

• Dimensions: 13-7/8 Inch L x 9 Inch H x 11-3/4 Inch D
• Weight: 83 pounds

Technical Specifications

• Body Material: Cast Iron
• Trim Material: Stainless Steel
• Pressure Rating: 175 psi
• Flow Rate (Cv): 150 Cv
• Temperature Range: 20 to 250 degrees Fahrenheit
• Connection Type: Flanged x Flanged
